Machine advantage:
1. This filling line specially produces 3&5 gallons barreled drinking water.
2. This series barreled filling production line integrates bottle washer, filler and sealer into one unit.
3. In order to achieve the purpose of washing and sterilizing, bottle washer adopts multiple liquid injections washing and disinfectant spray, and washing solution can be used circularly. The sealer can seal bottle caps automatically.
4. This filling line equips with water spraying device to sterilize caps of bottles in order to ensure those caps are aseptic and healthy.
5. This line also can automatically carry out bottle washing, sterilizing, filling, capping, counting and products discharging.
6. It has features of complete functional, novel design, and high degree of automation. It is a new kind of barreled water auto-producing line, which integrates mechanism, electricity and pneumatics technologies together.
Characteristic:
1.QGF type bottled production line specialize produce 3 gallons and 5 gallons bottled water.
2.The machine with all the function—washing , filling , screwing , it is an ideal equipment for producing mineral water , distilled water , pure water.
3.All the machine is made of stainless steel , anticorrosive , easy to clear. The main electrical elements use the SIEMENS,OMRON . Carrier gas system use the Air TAC .
4.The machine has small and exquisite structure , occupy a little space in the working room , high efficient working , stable and reliable, high automation .
5.All the operation just need 2 people.
Main technical parameters:
|
Model
|
Capacity production
|
power
|
Overall dimension
|
|
QGF-120
|
120b/h
|
2.8kw
|
2500*900*1445
|
|
QGF-200
|
200 b/h
|
3.3 kw
|
3000*1350*1560
|
|
QGF-300
|
300 b/h
|
4.5 kw
|
3500*1400*1560
|
|
QGF-600
|
600 b/h
|
5.7 kw
|
4500*3000*1560
|
|
QGF-900
|
900 b/h
|
6.5 kw
|
5100*3600*1560
|
|
QGF-1200
|
1200 b/h
|
8 kw
|
5100*1400*1560
|
Why our machine is better than other similar machines
1. Small profits and quick returns is our business policy, so the water bottling line is worth every cent.
2. We focus on advanced supply chain management, which can ensure the raw materials are with
good quality and competitive price.
3. Workers, engineers and boss of our company have spent more than 10 years in beverage
machinery industry,so they have rich experience to provide Turn Key project Service.
4. There are several engineers available to oversea service. As long as our customers need them,
they can leave for your country as soon as possible, our principle to let our production line always runsnormally.
5. We can update the production status for our customer once per week, our target is to let our
customer receive goods on time.
About our company
We can provide beverage filling line as below:
1).Complete mineral & pure water production line
2).Complete fruit juice production line
3).Complete soft drink production line
4).Gallons water production line
5). Beer filling & packaging line
We strictly manufacture and manage according to IOS9001 System.And we sincerely welcome customers all over the world visit our company,or visit our website.
After-sale servic
1. 1 year quality warranty and supply spare parts at low cost for life span after sale. We keep the original drawings of spare parts, so it can match with the rest part of machine.
2. 24 hours/365 days online technical service.
3. Training offered
